Moving Caster Kit

MCK – 60-2b_2x4p

Price $ 245.00 (+$45.00 s&h)

The Moving Caster Kit (MCK) is equipped with swivel casters - 6 inch (15cm) in diameter by 2 inch (5cm) wide Phenolic wheels with roller bearing. Two of the casters have cam lock brakes and the other two are equiped with four position swivel lock plungers. For precised movement the swivel should be locked in position - either at 90 degree for side movement or inline for forward movement. The swivel locks can be disengaged for a free swivel.

The MCK allows the project vehicle to be moved, while on the lift, to the work area. When done it could be moved back to the storage while you are waiting for parts or time to finish the work. The kit is handy for seasonal storage allowing you to move the vehicle during the storage time if needed. Some of our customers have used the MCK to make space for parking third car in a 2 or 2-1/2 car garage.

Installing the MCK is extremely easy.

Raise the EZcarlift™ 18+ inches (45+cm) and install the casters are installed on the lift's legs via quick release pin. When the MCK are engaged, the car will be approximately 16 inches (40cm) off the floor. Once attached, they could be left on the lift during its entire operation. They will have to be removed when the car will be lowered all the way down on its wheels.

The MCK is also very handy with the Motorcycle Lifting Kit and the Work Bench Kit.

Load capacity of the MCK is 3,500 lbs (1,6 ton) - above that weight it becomes extremely hard to maneuver the car.



NOTE: When the MCK is purchase separately from the EZcarlit, an Anti Friction Kit (AFK) has to be installed - Anti Friction Kit installation video (MCK purchased with the EZcarlift, already has the AFK installed)
